3n7b_AB : 3D-footprint complex

structure name	SGRAI BOUND TO SECONDARY SITE DNA AND CA(II)
reference	Horton et al. 'Acta 67 67 2011
source	Streptomyces griseus
experiment	X-ray (resolution=2.65, R-factor=?)
structural superfamily	Restriction endonuclease-like;
reference complex	6obj_A
links to other resources	NAKB PDIdb DNAproDB
protein sequence	> 3n7b_A interface=30,35,91,94,95,151,243,245,246,247,248, pftysieatrnlatterciqdirnapvrnRstqfQlaqqnmlaytfgevipgfasagingmdyrdvigrpvenavtegthffrddfrvdsNakAKvagdifeivssavmwncaarwnslmvgegwrsqprysrptlspsprrqvavlnlpRsfdwvsllvpesqevieefraglrkdglglptstpdlavvvlpeefqndemwreeiagltrpnqillsgayqrlqgrvqpgeislavafkrSlRSDRlyqplyeanvmqlllegklgapkvefevhtlapegtnafvtyeaaslyglarsavhrairelyvpptaadlarrffaflnermelvng > 3n7b_B interface=30,35,91,94,95,151,241,243,244,245,246, pftysieatrnlatterciqdirnapvrnRstqfQlaqqnmlaytfgevipgfasagingmdyrdvigrpvenavtegthffrddfrvdsNakAKvagdifeivssavmwncaarwnslmvgegwrsqprysrptlspsprrqvavlnlpRsfdwvsllvpesqevieefraglrglglptstpdlavvvlpeefqndemwreeiagltrpnqillsgayqrlqgrvqpgeislavafkrSlRSDRlyqplyeanvmqlllegklgapkvefevhtlapegtnafvtyeaaslyglaegvhrairelyvpptaadlarrffaflnermelvng
interface signature	RQNAKRSRSDR/RQNAKRSRSDR

readout + contact

# IC=8.834 IC/col=1.104 n_of_columns=8

A |   0  60   1   0   0   0   6   0
C |  95  12  95  96   0   0   8   0
G |   1  12   0   0  96  96  76  96
T |   0  12   0   0   0   0   6   0
