4z1x_B : 3D-footprint complex

structure name	CRYSTAL STRUCTURE OF LAGLIDADG HOMING ENDONUCLEASE I-GZEII IN COMPLEX WITH DNA TARGET (LAGLIDADG endonuclease)
reference	Stoddard et al. 'To ? ? ?
source	Fusarium graminearum PH-1
experiment	X-ray (resolution=2.80, R-factor=0.176)
structural superfamily	Homing endonucleases;
sequence family	LAGLIDADG endonuclease;
reference complex	4efj_A
links to other resources	NAKB PDIdb DNAproDB
protein sequence	> 4z1x_B interface=18,20,22,24,29,31,35,37,60,65,69,71,174,178,185,187,191,193,215,217,218,223,227,229, sinpwfvtgftdaegsfMiHlEkNkdkwRvRptfQiKldirdkslleeiknyfnntgsiNtsnkEcvyKvRslkdisiiishfdkynlitqkkadfelfkkiinklnsqehlsyevgatvlqeiisirasmnlglsssvkedfphiipsnrplienmniphpewmagfvsgegSfsvYttsddkYvSlsfRvSqhnkdkqllksfvdffgcggfNyHNkgnkAvifVtRkfedindkiiplfneykikgvkykdfkdwskvakmieskshlttngykeickikenmnsyrk
interface signature	MHENRRQKNEKRSYYSRSNHNAVR

Estimated binding specificities ?

readout + contact

# IC=24.845 IC/col=1.183 n_of_columns=21

specificity:

A |   0   0   0   0   0  96   0   0  70   0  96   0   0   0   0   0  96   0  96  51  64
C |   0   0   0   0   0   0  96  96   6   6   0   0   0   0   0   0   0  96   0  12   8
G |   0  96  96  96   0   0   0   0   8   0   0   0   0  96  96   0   0   0   0  21  12
T |  96   0   0   0  96   0   0   0  12  90   0  96  96   0   0  96   0   0   0  12  12
